Wavelets

Wavelet Objects

Given a continuous scaling function \(\phi(t)\) and a continuous wavelet function \(\psi(t)\), the discrete wavelet transform (DWT) of a continuous function \(x(t)\) is the projection onto the discrete basis of continuous functions defined by

\[\big{\{} \phi_{0, n}(t) \, \vert \, n \in \mathbb{Z} \big{\}} \cup \big{\{} \psi_{i, n}(t) \, \vert \, i \in \mathbb{N}, n \in \mathbb{Z} \big{\}}\]

where

\[\phi_{i, n}(t) = 2^{-i / 2} \, \phi(2^{-i} t - n) \quad \text{and} \quad \psi_{i, n}(t) = 2^{-i / 2} \, \psi(2^{-i} t - n)\]

That is, the DWT coefficients are

\[\langle x, \phi_{0, n} \rangle = \int x(t) \, \phi_{0, n}(t) \, dt \quad \text{and} \quad \langle x, \psi_{i, n} \rangle = \int x(t) \, \psi_{i, n}(t) \, dt\]

A Wavelet object represents a compactly supported wavelet function \(\psi(t)\) and scaling function \(\phi(t)\) in a way that is well suited for implementing discrete wavelet transforms. Specifically, it uses a FIR filter bank as prescribed by Mallet in his multiresolution analysis theory.

Note

Computationly, the function \(x(t)\) is represented discretely by \(N\) samples. This forces the scale parameter \(i\) to be finite, the translation parameter \(n\) to run from \(0\) to \(N\), and \(\langle \cdot, \cdot \rangle\) to be a sum instead of an integral.

Filter Bank

Given four discrete sets of coefficients, namely \(g_d[n]\), \(h_d[n]\), \(g_r[n]\), and \(h_r[n]\), a wavelet function \(\psi(t)\) and scaling function \(\phi(t)\) are implicitly defined by

\[\phi_{i, 0}(t) = \sum_n g_d[n] \phi_{i - 1, n}(t) = \sum_n g_r[n] \phi_{i + 1, n}(t)\]

\[\psi_{i, 0}(t) = \sum_n h_d[n] \phi_{i - 1, n}(t) = \sum_n h_r[n] \phi_{i + 1, n}(t)\]

For well defined wavelets, the coefficients must satisify an admissibility constraint. Additional constraints are often imposed to enusre various properties such as orthogonality, regularity, etc. See “Wavelets and Filter Banks” by Strang & Nguyen for the details.

One of the principal advantages of this formulation is that the multiscale DWT can be realized by recursive applications of a filter_bank() that uses these coefficients as convolution kernels.

Decomposition

Image decomposition is accomplished by a two stage cascade where each stage is a two channel filter bank consisting of a lowpass filter \(g_d[n]\) and a highpass filter \(h_d[n]\). At each stage, both channels are downsampled by a factor of two. The first stage convolves along rows and downsamples columns. The second stage convolves along columns and downsamples rows. This results in four outputs:

• Approximation Subband Coefficients (Lowpass-Lowpass)

• Horizontal Detail Subband Coefficients (Lowpass-Highpass)

• Vertical Detail Subband Coefficients (Highpass-Lowpass)

• Diagonal Detail Subband Coefficients (Highpass-Highpass)

Decomposition Block Diagram

Reconstruction

Image reconstruction revserses the signal flow, uses the reconstruction kernels \(g_r[n]\) and \(h_r[n]\), and upsamples instead of downsampling.

Reconstruction Block Diagram

Accessing Filter Bank Kernels

For some wavelet

Wavelet wavelet = ...;

the decomposition kernels are

wavelet.filter_bank().decompose_kernels().lowpass();
wavelet.filter_bank().decompose_kernels().highpass();

and the reconstruction kernels are

wavelet.filter_bank().reconstruct_kernels().lowpass();
wavelet.filter_bank().reconstruct_kernels().highpass();

Properties

Each wavelet object has a name() and family() name. Whenever possible, the name() uniquely identifies the filter bank used to define the wavelet. This is true for all predefined wavelets.

Wavelets have the additional properties:

• orthogonality()

• symmetry()

• wavelet_vanishing_moments()

• scaling_vanishing_moments()

Predefined Wavelets

The following predefined wavelets can be constructed by the indicated factory or by Wavelet::create() using one of the indicated names.

• Haar

  • Factory: create_haar()

  • Names: haar

• Daubechies

  • Factory: create_daubechies()

  • Names: db1, db2, …, db38

• Symlets

  • Factory: create_symlets()

  • Names: sym2, sym3, …, sym20

• Coiflets

  • Factory: create_coiflets()

  • Names: coif1, coif2, …, coif17

• Biorthogonal

  • Factory: create_biorthogonal()

  • Names:

    • bior1.1

    • bior1.3

    • bior1.5

    • bior2.2

    • bior2.4

    • bior2.6

    • bior2.8

    • bior3.1

    • bior3.3

    • bior3.5

    • bior3.7

    • bior3.9

    • bior4.4

    • bior5.5

    • bior6.8

• Reverse Biorthognal

  • Factory: create_reverse_biorthogonal()

  • Names:

    • rbior1.1

    • rbior1.3

    • rbior1.5

    • rbior2.2

    • rbior2.4

    • rbior2.6

    • rbior2.8

    • rbior3.1

    • rbior3.3

    • rbior3.5

    • rbior3.7

    • rbior3.9

    • rbior4.4

    • rbior5.5

    • rbior6.8

Custom Wavelets

Custom wavelets are created by providing a FilterBank constructed directly from four kernels or by one of the factory functions:

• FilterBank::create_orthogonal()

• FilterBank::create_biorthogonal()

• FilterBank::create_conjugate_mirror()

• FilterBank::create_quadrature_mirror()

It is encouraged, but not required, that each wavelet is given a name() and family(). If possible, the name should uniquely identify the filter bank. See the naming schemes used for the builtin wavelets for examples.

Create a wavelet from filter bank kernels.

cv::Mat decomposition_lowpass_kernel = ...;
cv::Mat decomposition_highpass_kernel = ...;
cv::Mat reconstruction_lowpass_kernel = ...;
cv::Mat reconstruction_highpass_kernel = ...;

auto filter_bank = FilterBank(
    decomposition_lowpass_kernel,
    decomposition_highpass_kernel,
    reconstruction_lowpass_kernel,
    reconstruction_highpass_kernel
);

auto wavelet = Wavelet(filter_bank, "myname", "My Family");

Or equivalently, use the convienence Wavelet constructor to skip creating the filter bank directly.

// The filter bank is built internally.
auto wavelet = Wavelet(
    decomposition_lowpass_kernel,
    decomposition_highpass_kernel,
    reconstruction_lowpass_kernel,
    reconstruction_highpass_kernel,
    "myname",
    "My Family"
);

When a wavelet is constructed from four filter kernels, it is up to the user to ensure that the wavelet is well defined. The satisfies_alias_cancellation(), satisfies_no_distortion(), is_biorthogonal(), and is_orthogonal() functions may be helpful in this regard.

Orthogonal Wavelets

Use the FilterBank::create_orthogonal() factory to create an orthogonal wavelet from a reconstruction lowpass kernel.

cv::Mat reconstruction_lowpass_kernel = ...;
auto filter_bank = FilterBank::create_orthogonal(reconstruction_lowpass_kernel);

auto wavelet = Wavelet(filter_bank, "myname", "My Family");

Or equivalently, use the convienence Wavelet constructor to skip creating the filter bank directly.

// The filter bank is built internally using FilterBank::create_orthogonal.
auto wavelet = Wavelet(reconstruction_lowpass_kernel, "myname", "My Family");

FilterBank::create_orthogonal() normalizes the kernel using the L2 norm before creating a conjugate mirror filter bank and ensuring that the filter bank is_orthogonal(). Use FilterBank::create_conjugate_mirror() to avoid the normalization and the is_orthogonal() check.

Biorthogonal Wavelets

Use the FilterBank::create_biorthogonal() factory to create a biorthogonal wavelet from a pair of reconstruction and decomposition lowpass kernels.

cv::Mat reconstruction_lowpass_kernel = ...;
cv::Mat decomposition_lowpass_kernel = ...;
auto filter_bank = FilterBank::create_biorthogonal(
    reconstruction_lowpass_kernel,
    decomposition_lowpass_kernel
);

auto wavelet = Wavelet(filter_bank, "myname", "My Family");

Or equivalently, use the convienence Wavelet constructor to skip creating the filter bank directly.

// The filter bank is built internally using FilterBank::create_biorthogonal.
auto wavelet = Wavelet(
    reconstruction_lowpass_kernel,
    decomposition_lowpass_kernel,
    "myname",
    "My Family"
);

FilterBank::create_biorthogonal() normalizes the kernel using the L2 norm by before creating a quadrature mirror filter bank and ensuring that the filter bank is_biorthogonal(). Use FilterBank::create_quadrature_mirror() to avoid the normalization and the is_biorthogonal() check.

Constructing Custom Wavelets By Name

Providing support for creating custom wavelets by name is straightforward - simply implement a wavelet factory and register each possible parameter set with Wavelet::register_factory(). For example, the predefined Daubechies wavelets are registered at startup using code equivalent to the following.

for (int order = 1; order < 39; ++order)
    Wavelet::register_factory(create_daubechies, order);

So that creating a 4th order Daubechies wavelet by name is done with

Wavelet db4_wavelet = Wavelet::create("db4");

Under the hood, std::bind() binds order to create_daubechies() and uses the name() of the wavelet (e.g. “db1”) as the factory name.

Follow this approach whenever the wavelet name() uniquely identifies an entire set of factory parameters.

If, however, it is impossible or inpractical to enumerate all possible sets of factory parameters, or the wavelet name() does not uniquely identify the filter_bank(), use the version of Wavelet::register_factory() that takes a factory name and registers a factory that accepts unbound parameters at creation.

API Reference

Wavelet API
